ABAC EXT A39B 200 CM3 UK (c.f.m. - 14, L/min. - 396)
ABAC EXT A39B 200 CM3 UK (c.f.m. - 14, L/min. - 396)
Couldn't load pickup availability


EXT A39B 200 CM3 UK
Extensive Series Single stage belt driven piston compressors
ABAC’s EXtensive range: Is the result of meticulous engineering aimed at delivering a product that doesn’t compromise on performance or value.
The EXtensive range from ABAC is designed to meet every market requirement, offering a versatile solution that are suitable for all users: whether you're a hobbyist or you are looking for a professional air compressor, the EXtensive range offers a solution for your specific requirements.
Features and Benefits :-
Ergonomically designed belt guards providing optimal cooling
- Cast Iron cylinder blocks fitted as standard
- Aftercoolers fitted as standard for reduced operating temperatures
- Low operating speed for increased longevity
- pressure regulators fitted as standard with quick release coupling for efficient tooling connection
- Additional safety thanks to the lockable front swivel wheel
- Ergonomic, robust handle for increased user comfort.
- Motor overload switches fitted standard for increased protection
- User-friendly Clear pump oil level indicators
- Large and easy to operate drain valve
- 200mm robust rear wheels for multiple terrains
- Motor pre wired ready to accept 16 amp
- plug
| Item number | 4116028557 |
|---|---|
| Product Name | EXT A39B 200 CM3 UK |
| Oil Free | No |
| Air Displacement (cfm) | 13.8 |
| Free Air Delivery (cfm) | 10.1 |
| Product category | Piston compressors |
| Air hose attachment (inch) | Universal quick coupling |
| Suitable for | Professional |
| Horsepower (HP) | 3 |
| Power (kW) | 2.2 |
| Brand | ABAC |
| Air receiver capacity (Lt) | 200 |
| Starter | Direct on line |
| Revolutions per minute (RPM) | 1050 |
| Type | Belt driven |
| Number of cylinders | 2 |
| Weight (kg) | 129 |
| Width (mm) | 1413 |
| Mobility | Mobile |
| Depth (mm) | 572 |
| Height (mm) | 1008 |
| Voltage (V) | 230 |
| Integrated dryer | No |
| Frequency (Hz) | 50 |
| Phase | 1 |
| Maximum air pressure (bar) | 10 |
| Cooling type | Air |
| Sound level LpA at 4m distance | 75 |
| Sound level LwA | 95 |
| Used for | Piston compressor |
